Products > Linear Regulator > Daul Output LDO Regulator | |||||||||||||
Part_No | Package | Input Voltage (V) | Quies. Curren -tu(uA) | Fixed Output Voltage 1(V) | Fixed Output Voltage 2(V) | Output Current 1(max) A | Output Current 2 max A | Dropout Voltage 1(V) | Dropout Voltage 2(V) | EN | High PSRR | Low Noise | |
min | max | ||||||||||||
SOP-8 | 4.75 | 8 | 10000 | 3.3 | 2.5 | 0.5 | 0.3 | 1.25 | 1.2 | N | N | N | |
SOP-8 | 4.2 | 6 | 100 | 3.3 | 2.5 | 0.5 | 0.5 | 0.5 | 0.6 | N | N | N | |
SOP-8/p | 4.2 | 6 | 100 | 3.3 | 1.8 | 0.5 | 0.3 | 0.6 | 0.9 | N | N | N | |
SOP-8/p | 4.15 | 6 | 130 | 3.3 | 2.5 | 0.5 | 0.5 | 0.55 | 0.63 | Y | N | N | |
SOT26/TSOT26 TDFN1.6x1.6-6 | 2.5 | 5.5 | 68 | 1.2-3.3 | 1.2-3.3 | 0.3 | 0.3 | 0.27 | 0.27 | Y | Y | Y | |
TSOT236A TDFN1.6x1.6-6 | 2.5 | 5.5 | 58 | 1.2-3.3 | 1.2-3.3 | 0.3 | 0.3 | 0.24 | 0.24 | Y | Y | Y | |
SOP-8/p | 3.95 | 6 | 110 | 3.3 | 3.3 | 0.3 | 0.3 | 0.35 | 0.35 | Y | N | N | |
SOP-8/p | 4.15 | 6 | 110 | 3.3 | 3.3 | 0.5 | 0.5 | 0.5 | 0.5 | Y | N | N | |
SOP-8/p | 4.1 | 6 | 110 | 3.3 | 2.8 | 0.5 | 0.5 | 0.45 | 0.5 | Y | N | N | |
TDFN1.5x1.5-6 | 2 | 5.5 | 58 | 1.2~3.3 | 1.2~3.3 | 0.3 | 0.3 | 0.24 | 0.24 | Y | Y | Y | |
TDFN1.6x1.6-6 | 2 | 5.5 | 58 | 1.2~3.3 | 1.2~3.3 | 0.3 | 0.3 | 0.24 | 0.24 | Y | Y | Y | |
