CXSD62500是一款高效、1.5μa超低静态电流、同步降压DC/DC稳压器，专为单电池锂离子或锂聚合物电池供电的应用而设计。它可以在2.5V到5.5V的宽输入电压范围内工作，并将主开关和同步开关与极低的RDS（ON）集成，以最大限度地降低传导损耗
-
[ 产品资料下载 ]
目录
7.相关产品
产品概述 返回TOP
CXSD62500 is a high efficiency, 1.5μA ultra low quiescent current, synchronous step down DC/DC regulator special designed for one-cell Li-Ion or Li-polymer battery powered applications. It can operate over a wide input voltage range from 2.5V to 5.5V and integrate main switch and synchronous switch with very low RDS (ON) to minimize the conduction loss.
产品特点 返回TOP
· 2.5~5.5V Input Voltage Range
· 1.5μA Typical Quiescent Current
· Low RDS(ON) for Internal Switches (Top/Bottom) : 0.4/0.2Ω
· Typical 450mA Peak Current Limit
· Internal Soft-start Limits the Inrush Current
· RoHS Compliant and Halogen Free
· Compact Package: DFN2x2-8
应用范围 返回TOP
· Battery Powered Applications
· Consumer and Portable Medical Products
· Personal Care Products
技术规格书（产品PDF) 返回TOP
需要详细的PDF规格书请扫一扫微信联系我们，还可以获得免费样品以及技术支持！
产品封装图 返回TOP
电路原理图 返回TOP
相关芯片选择指南 返回TOP 更多同类产品。。。。
|
