CXSD62181是一个集成功率mosfet的3A同步降压转换器。设计采用电流模式控制方案，可将7.5V至24V的宽输入电压转换为0.8V至20V的可调输出电压，提供良好的输出电压调节。CXSD62181配备了强制脉宽调制模式操作。CXSD62181还配备了上电复位、软启动和整体保护（欠压、过压、超温、限流）成一个整体。
-
[ 产品资料下载 ]
目录
7.相关产品
产品概述 返回TOP
CXSD62181 is a 3A synchronous buck converter with integrated power MOSFETs. The CXSD62181 design with a current-mode control scheme, can convert wide input voltage of 7.5V to 24V to the output voltage adjustable from 0.8V to 20V to provide excellent output voltage regulation. The CXSD62181 is equipped with force PWM mode operation. The CXSD62181 is also equipped with Power-on-reset, soft start and whole protections (under-voltage, over-voltage, over-temperature and current-limit) into a single package. This device, available TDFN3x3-10 provides a very compact system solution external components and PCB area.
产品特点 返回TOP
· Wide Input Voltage Range from 7.5V to 24V
· 3A Continuous Output Current
· Adjustable Output Voltage from 0.8V to 20V
· VREF=0.8V+1% over all Load & Line Regulation & TC Range
· Integrated High/Low Side MOSFET
· High Efficiency Performance up to 95% scale
· Low Shutdown Current<1mA scale
· Built-in Internal 1.5ms Soft-Start & Soft-Stop Functions
· Fixed 600kHz Switching Frequency with Maximum 90% Duty
· Force PWM Mode Operation
· Built-in Current Mode Control for Fast Response & MLCC supports with Internal
· Stable with Low ESR Capacitors
· Power-On-Reset Detection on VCC & VIN
· Over-Temperature Protection
· Over Voltage Protection
· Current-Limit Protection with Frequency Foldback
· Enable/Shutdown Function
· Current-Mode Operation with Internal Compensation
· Small TDFN3x3-10 packages
· Lead Free and Green Devices Available (RoHS compliant)
应用范围 返回TOP
· Notebook Computer & UMPC
· LCD Minitor/TV
· Set-Top Box
· DSL, Switch HUB · Portable Instrument
技术规格书（产品PDF) 返回TOP
需要详细的PDF规格书请扫一扫微信联系我们，还可以获得免费样品以及技术支持！
产品封装图 返回TOP
电路原理图 返回TOP
相关芯片选择指南 返回TOP 更多同类产品.......
|
