CXLD64102是一个3针低压差线性稳压器，输出电压在线、负载和温度变化的精度为2.0%。CXLD64102的输出电流容量大于500mA。500毫安输出电流时的电压降小于1.5伏（最大值）。输出电流限制和热关断内置，以提供最大的保护，以防止故障情况下的变压器
-
[ 产品资料下载 ]
目录
7.相关产品
产品概述 返回TOP
The CXLD64102 is a 3-pin low dropout linear regulator with 2.0% accuracy of output voltage over line , load and temperature variations. The output current capability of CXLD64102 is over 500mA. Dropout voltage at 500mA output current is less than 1.5V(max). Both output current limiting and thermal shutdown are built in to provide maximal protection to the CXLD64102 against fault conditions. The over current and thermal shutdown circuits become active when the current exceed 500mA , or the junction temperature reach 150°C. Normal operation is recovered when junction temperature drops below 130°C.
产品特点 返回TOP
• Output Voltage Accuracy ± 2.0%
• Line Regulation - 1mV (typ.)
• Load Regulation - 6mV (typ.)
• Input Voltage Range up to 9V
• Internal Current Limiting and Thermal Shut- down Protections
• SOT-89 and TO-92 Packages Available
应用范围 返回TOP
• Voltage Regulator for CD-ROM Drivers
• Voltage Regulator for LAN Cards
• Voltage Regulator for mother Boards
• Wireless Communication Systems
• Portable Instrument
• Portable Consumer Equipment
• Low Voltage Systems
技术规格书（产品PDF) 返回TOP
